24V 15A BMS with Key Switch
Use Mouse Wheel to Zoom In/Out
24V 15A BMS with Key Switch
Users feedback
| Price: |
|
|---|---|
| Freight costs: | From € 6,00 VAT included (22%)Details |
| Item code: | SINCBMS24V15A |
| Brand: | Capobranco |
| Availability: | Available (30 PZ)
Delivery 24/48h working (30 PZ) |
| Quantity: |
Description
24V 15A BMS for 24V lithium battery packs
BMS board for lithium batteries with key switch.
This module allows for the monitoring and balancing of the various cell series.
TECHNICAL SPECIFICATIONS:
- Operating voltage: 29.6V
- Number of cells: 7S
- Operating temperature: -20°C to 45°C
- Charging current: 5A MAX
- Rated discharge current: 15A
- Protections: Overcharge, over-discharge, and short circuit.
DIMENSIONS: 6.5 x 3.5 x 1 cm
For any technical information regarding compatibility, our technicians are available at 3206140014, including via WhatsApp. Capobranco Project is not liable for tampering or incorrect installation. Components are tested prior to shipment. Capobranco Project provides a 6-month warranty on all spare parts. Our products are stocked and shipped from our facility in Italy.
